连续式跨声速风洞流场湍流度测试实验研究

朱博 陈吉明 吴巍 裴海涛

朱博,陈吉明,吴巍,等. 连续式跨声速风洞流场湍流度测试实验研究[J]. 实验流体力学,2022,36(X):1-9 doi: 10.11729/syltlx20220034
引用本文: 朱博,陈吉明,吴巍,等. 连续式跨声速风洞流场湍流度测试实验研究[J]. 实验流体力学,2022,36(X):1-9 doi: 10.11729/syltlx20220034
ZHU B,CHEN J M,WU W,et al. Experimental investigation of turbulence intensity measurement in continuous transonic wind tunnel[J]. Journal of Experiments in Fluid Mechanics, 2022,36(X):1-9. doi: 10.11729/syltlx20220034
Citation: ZHU B,CHEN J M,WU W,et al. Experimental investigation of turbulence intensity measurement in continuous transonic wind tunnel[J]. Journal of Experiments in Fluid Mechanics, 2022,36(X):1-9. doi: 10.11729/syltlx20220034

连续式跨声速风洞流场湍流度测试实验研究

doi: 10.11729/syltlx20220034
详细信息
    作者简介:

    朱博:(1973—),男,广西百色人,硕士研究生,高级工程师。研究方向:风洞流场测试与分析技术,热线技术,测控技术。通信地址:四川省绵阳市二环路南段6号12信箱1分箱 (621000)。E-mail:bobjou@139.com

    通讯作者:

    E-mail:bobjou@139.com

  • 中图分类号: V211.7;O357.5

Experimental investigation of turbulence intensity measurement in continuous transonic wind tunnel

  • 摘要: 使用恒温式热线风速仪(CTA)完成了0.6m连续式跨声速风洞换热器入口至试验段流场湍流度测量;采用二维热线探头旋转方法,完成了换热器入口至稳定段出口的低速流场三维湍流度分布测试;采用一维探头连续变热线过热比方法,完成了试验段跨声速流场湍流度测试,测试流场速度最高马赫数为1.5。研究结果表明:换热器段和稳定段是重要的降湍部段,均可降低湍流度90%以上;稳定段阻尼网从3层增加至5层,可降低稳定段湍流度50%,可降低试验段湍流度17%;采用CTA连续变热线过热比方法可以获得试验段可压流场的扰动图(反映了试验段流场的扰动特征)和湍流度值,马赫数为0.4的流场扰动图呈一阶线性特征,马赫数为0.7的流场扰动图呈现双曲线特征。实验结果可为连续式跨声速风洞流场湍流度评估和优化提供依据。
  • 图  1  热线探头测点分布

    Figure  1.  Hot wire probes setting for measurement

    图  2  稳定段出口测点

    Figure  2.  Measuring point in the exit of setting chamber

    图  3  试验段测点

    Figure  3.  Measuring point in test section

    图  4  吹断的探头热丝

    Figure  4.  Hot wire of probe broken by flow

    图  5  换热器入口湍流度分布

    Figure  5.  Turbulence intensity distribution at the entrance of heat exchanger

    图  6  换热器出口湍流度分布

    Figure  6.  Turbulence intensity distribution in the exit of heat exchanger

    图  7  四拐入口湍流度分布

    Figure  7.  Turbulence intensity distribution in the entrance of the 4th corner

    图  8  稳定段入口湍流度分布

    Figure  8.  Turbulence intensity distribution at the entrance of setting chamber

    图  9  3层阻尼网稳定段出口湍流度分布

    Figure  9.  Turbulence intensity distribution at the exit of setting chamber with 3 screens

    图  10  三层阻尼网与五层阻尼网的稳定段出口湍流度比较

    Figure  10.  Comparison of setting chamber exit turbulence intensity between 3 screens and 5 screens

    图  11  风洞回路流向湍流度分布

    Figure  11.  Comparison of turbulence intensity between 3 screens and 5 screens

    图  12  Ma0.4三层阻尼网试验段流场扰动图

    Figure  12.  Ma0.4 flow fluctuation diagram in 3 screens test section

    图  13  Ma0.7三层阻尼网试验段流场扰动图

    Figure  13.  Ma0.7 flow fluctuation diagram in 3 screens test section

    图  14  Ma0.4三层阻尼网试验段热线脉动电压幅值谱

    Figure  14.  Ma0.4 frequency spectrum of hot wire voltage fluctuation amplitude in 3 screens test section

    图  15  Ma0.4五层阻尼网试验段流场扰动图

    Figure  15.  Ma0.4 flow fluctuation diagram in 5 screens test section

    图  16  Ma0.7五层阻尼网试验段流场扰动图

    Figure  16.  Ma0.7 flow fluctuation diagram in 5 screens test section

    图  17  三层阻尼网和五层阻尼网试验段流场湍流度比较

    Figure  17.  Turbulence level comparison between 3 screens and 5 screens in test section

    表  1  不同阻尼网层数试验段湍流度测量结果

    Table  1.   Turbulence level result for different screen layers in test section

    阻尼网马赫数湍流度
    <u>, %
    拟合优度不确定度/
    %
    三层0.40.0700.9870.0012
    三层0.70.0540.9810.0003
    五层0.40.0560.9820.0014
    五层0.70.0470.9690.0013
    下载: 导出CSV
  • [1] 郝礼书,乔志德,武洁,等. NF-6风洞AV90-2轴流压缩机喘振曲线测试研究[J]. 西北工业大学学报,2009,27(4):477-480. doi: 10.3969/j.issn.1000-2758.2009.04.009

    HAO L S,QIAO Z D,WU J,et al. Critically investigating anti-surge monitor and control system of AV90-2 axial compressor in NWPU NF-6 wind tunnel[J]. Journal of Northwestern Polytechnical University,2009,27(4):477-480. doi: 10.3969/j.issn.1000-2758.2009.04.009
    [2] 廖达雄,陈吉明,彭强,等. 连续式跨声速风洞设计关键技术[J]. 实验流体力学,2011,25(4):74-78. doi: 10.3969/j.issn.1672-9897.2011.04.014

    LIAO D X,CHEN J M,PENG Q,et al. Key design techniques of the low noise continuous transonic wind tunnel[J]. Journal of Experiments in Fluid Mechanics,2011,25(4):74-78. doi: 10.3969/j.issn.1672-9897.2011.04.014
    [3] 陈吉明,吴盛豪,陈振华,等. 连续式跨声速风洞回路吸声降噪技术试验研究[J]. 西北工业大学学报,2020,38(4):855-861. doi: 10.3969/j.issn.1000-2758.2020.04.021

    CHEN J M,WU S H,CHEN Z H,et al. Experimental research on noise reduction for continuous transonic wind tunnel loop[J]. Journal of Northwestern Polytechnical University,2020,38(4):855-861. doi: 10.3969/j.issn.1000-2758.2020.04.021
    [4] 毕卫涛,唐帆,胡永煌,等. 基于结构系综理论发展可靠工程转捩模型的一种新思路[J]. 空气动力学学报,2020,38(6):1136-1148. doi: 10.7638/kqdlxxb-2020.0123

    BI W T,TANG F,HU Y H,et al. New perspective for developing reliable engineering transition model based on the structural ensemble dynamics theory[J]. Acta Aerodynamica Sinica,2020,38(6):1136-1148. doi: 10.7638/kqdlxxb-2020.0123
    [5] 高超,王娜,袁先士,等. NF-6增压连续式高速风洞压缩机喘振边界的确定[J]. 实验流体力学,2013,27(5):61-66. doi: 10.3969/j.issn.1672-9897.2013.05.011

    GAO C,WANG N,YUAN X S,et al. Determination of the axial-flow compressor surge boundary in NF-6 pressurized continuously-operating high-speed wind tunnel[J]. Journal of Experiments in Fluid Mechanics,2013,27(5):61-66. doi: 10.3969/j.issn.1672-9897.2013.05.011
    [6] 陈旦,杨孝松,李刚,等. 连续式风洞总压和调节阀相关性研究及其应用[J]. 西北工业大学学报,2020,38(2):325-332. doi: 10.3969/j.issn.1000-2758.2020.02.013

    CHEN D,YANG X S,LI G,et al. Relativity research of total pressure and regulating valve in continuous wind tunnel and its application[J]. Journal of Northwestern Polytechnical University,2020,38(2):325-332. doi: 10.3969/j.issn.1000-2758.2020.02.013
    [7] 赵波,符澄,裴海涛,等. 椭圆翅片管对风洞气流湍流特性影响研究[J]. 西北工业大学学报,2020,38(2):303-308. doi: 10.3969/j.issn.1000-2758.2020.02.010

    ZHAO B,FU C,PEI H T,et al. Study on the effect of oval tubes on airflow turbulence characteristics in wind tunnel[J]. Journal of Northwestern Polytechnical University,2020,38(2):303-308. doi: 10.3969/j.issn.1000-2758.2020.02.010
    [8] 朱博,汤更生. 声学风洞流场低湍流度及频谱测量研究[J]. 实验流体力学,2015,29(4):58-64. doi: 10.11729/syltlx20140118

    ZHU B,TANG G S. Low turbulence intensity and spectrum measurement research in aeroacoustic wind tunnel[J]. Journal of Experiments in Fluid Mechanics,2015,29(4):58-64. doi: 10.11729/syltlx20140118
    [9] 杜钰锋,林俊,王勋年,等. 变热线过热比可压缩流湍流度测量方法优化[J]. 航空学报,2019,40(12):123067. doi: 10.7527/S10006-893.2019.23067

    DU Y F,LIN J,WANG X N,et al. Measurement technique optimization of turbulence level in compressible fluid by changing overheat ratio of hot wire anemometer[J]. Acta Aeronautica et Astronautica Sinica,2019,40(12):123067. doi: 10.7527/S10006-893.2019.23067
    [10] 何克敏,白存儒,郭渠渝,屠兴. 较低湍流度范围湍流度对风洞实验结果的影响[J]. 流体力学实验与测量,1997,11(3):11-17.

    HE K M,BAI C R,GUO Q Y,et al. The effect of turbulence on wind tunnel results in the range of low turbulence[J]. Experiments and Measurements in Fluid Mechanics,1997,11(3):11-17.
    [11] 李峰,白存儒,周伟,等. 湍流度对飞行器模型大迎角气动特性影响的初步研究[J]. 实验流体力学,2006,20(3):45-47,52. doi: 10.3969/j.issn.1672-9897.2006.03.009

    LI F,BAI C R,ZHOU W,et al. Primal research of the effect of flow turbulence on aerodynamic characteristics of a aircraft model at high angles of attack[J]. Journal of Experiments in Fluid Mechanics,2006,20(3):45-47,52. doi: 10.3969/j.issn.1672-9897.2006.03.009
    [12] KOVASZNAY L S G. The hot-wire anemometer in supersonic flow[J]. Journal of the Aeronautical Sciences,1950,17(9):565-572. doi: 10.2514/8.1725
    [13] STAINBACK P, JOHNSON C, BASNETT C. Preliminary measurements of velocity, density and total temperature fluctuations in compressible subsonic flow[C]//Proc of the 21st Aerospace Sciences Meeting. 1983: 384. doi: 10.2514/6.1983-384
    [14] CHOU A, LEIDY A, KING R A, et al. Measurements of freestream fluctuations in the NASA langley 20-inch Mach 6 tunnel[C]//Proc of the 2018 Fluid Dynamics Conference. 2018. doi: 10.2514/6.2018-3073
    [15] KING R A,ANDINO M Y,MELTON L,et al. Flow disturbance measurements in the national transonic facility[J]. AIAA Journal,2013,52(1):116-130. doi: 10.2514/1.J052429
    [16] BAUINGER S, BEHRE S, LENGANI D, et al. On turbulence measurements and analyses in a two-stage two-spool turbine rig[J]. Journal of Turbomachinery, 2017, 139(7). doi: 10.1115/1.4035508
    [17] ANDREWS G, POGGIE J. Effects of freestream acoustic disturbances on hypersonic boundary layer stability[C]//Proc of the AIAA AVIATION 2020 FORUM, VIRTUAL EVENT. Reston, Virginia: AIAA, 2020: 2995. doi: 10.2514/6.2020-2995
    [18] 马护生,时培杰,李学臣,等. 可压缩流体热线探针校准方法研究[J]. 空气动力学学报,2019,37(1):55-60. doi: 10.7638/kqdlxxb-2016.0093

    MA H S,SHI P J,LI X C,et al. Investigation of calibration method for hot-wire probe in compressible flow[J]. Acta Aerodynamica Sinica,2019,37(1):55-60. doi: 10.7638/kqdlxxb-2016.0093
    [19] 袁湘江,沙心国,时晓天,等. 高超声速流动中噪声与湍流度的关系[J]. 航空学报,2020,41(11):123791. doi: 10.7527/S10006893.2020.23791

    YUAN X J,SHA X G,SHI X T,et al. Noise-turbulence relationship in hypersonic flow[J]. Acta Aeronautica et Astronautica Sinica,2020,41(11):123791. doi: 10.7527/S10006893.2020.23791
    [20] 朱博,刘琴,屈晓力,等. 阵风发生装置流场测量与分析[J]. 实验流体力学,2013,27(6):76-80. doi: 10.3969/j.issn.1672-9897.2013.06.014

    ZHU B,LIU Q,QU X L,et al. Measurement and analysis of a gust generator flow field in wind tunnel[J]. Journal of Experiments in Fluid Mechanics,2013,27(6):76-80. doi: 10.3969/j.issn.1672-9897.2013.06.014
