The development of the movable solid wall test section for the 5.5 m × 4.0 m acoustic wind tunnel

YANG Wenguo; SHI Yan; WANG Rui

doi:10.11729/syltlx20220061

Volume 37 Issue 6

Dec. 2023

Turn off MathJax

Article Contents

Abstract

References

Journal of Experiments in Fluid Mechanics > 2023 > 37(6): 86-91. > DOI: 10.11729/syltlx20220061

YANG W G, SHI Y, WANG R. The development of the movable solid wall test section for the 5.5 m × 4.0 m acoustic wind tunnel[J]. Journal of Experiments in Fluid Mechanics, 2023, 37(6): 86-91. DOI: 10.11729/syltlx20220061

Citation:

PDF (11454 KB)

The development of the movable solid wall test section for the 5.5 m × 4.0 m acoustic wind tunnel

Facility Design and Instrumentation Institute, China Aerodynamics Research and Development Center, Mianyang　621000, China

More Information

Received Date: June 29, 2022
Revised Date: September 22, 2022
Accepted Date: September 22, 2022
Available Online: June 14, 2023

Graphical Abstract

Abstract

Abstract

According to the design indexes and functional requirements of the movable solid wall test section for the 5.5 m × 4.0 m acoustic wind tunnel, this report presents the design project of overall scheme. The simulation calculation is carried out for the strength, stiffness and mode of the frame in the movable solid wall test section. The key technologies of positioning and locking, lifting mechanism, replaceable lower wall panel and adjustable opening side wall panel are studied in detail. At the same time, specific solutions are provided for the key problems in its processing and assembly process. The above research contents have important reference value for the design of the closed test section of the large acoustic wind tunnel of the same type.
